JRready JRSSW-CP20 2-Pin Crimp Female Butt Connector Industrial Waterproof Connector
1. Compatible Wire Range: 14AWG ~ 18AWG (0.75mm² ~ 2.5mm²);
2. Termination Method: Crimping;
3. Removable Terminals;
4. Rated current: 16A Max; Rated voltage: 500V AC;
5. Waterproof Rating: IP68 (Mated state);
6. Salt Spray Test: 72h;
7. Flammability Rating: UL94 V-0
2. Termination Method: Crimping;
3. Removable Terminals;
4. Rated current: 16A Max; Rated voltage: 500V AC;
5. Waterproof Rating: IP68 (Mated state);
6. Salt Spray Test: 72h;
7. Flammability Rating: UL94 V-0
| Brand | JRready | Part Number | JRSSW-CP20-FP02-A0-SCN0013 |
| Category | JRSSW Series Connectors | Colour | Bright Chrome + Black |
| Material | Zinc Alloy (Single-Port Socket Base) 、PBT+PC | Dimension | 67*32.7*27.9（mm） |
| Country of Origin | China | Weight | 52.1g |
| Application | Applied in industrial automation, marine systems, energy sector, and urban infrastructure sectors. | ||
| Working Temperature | -40℃~+80℃ | Working Pressure | / |
| Rated Voltage | 500V AC | Rated Current | 16A Max |
